Explore the earth on our most powerful eBike with up to 100 real world miles of range. It's easy to ride and practically maintenance-free. It also offers a fully integrated in-frame primary battery, and an optional secondary battery which doubles your available range.
The New EVELO Atlas
Never worry about hills or battery life
Starts Shipping in February - Stock is Limited
Why Riders Love the Atlas
More Power
You can ride this bike anywhere with the most power & torque available in its class.
More Range
Never run out of battery. Ride up to 60 mile range or upgrade for up to 100 miles
More Fun
Enjoy the smoothest ride without the headaches of bike maintenance.
Atlas Overview
It's great for
- Light Trails & Off-Road
- City Riding & Commuting
- Touring & Bike Camping
Best fit for riders
- Rider Height 5'6" to 6'3"
- Rider Weight up to 350lbs
- Neutral Riding Position
Built to Last
- Bafang M600 Mid-Drive
- Enviolo CVT Gearing
- Gates CDX Belt Drive
Atlas
Upgrade to 100 Miles of Range
Never worry about getting home before the battery dies.
The Atlas is dual battery ready with our add-on integrated rear rack system, allowing for two batteries to be installed simultaneously and unparalleled mileage and ride time.
Combined, the batteries offer up to a 100 miles of real world riding. When utilizing both batteries, the system will automatically switch from the main integrated frame battery to the secondary battery seamlessly, ensuring your ride is uninterrupted.
A Premium eBike Built to Last
Powerful Class III Motor System
EVELO has teamed up with the engineers at Bafang (the worlds largest eBike motor Manufacturer) to release a custom tuned version of their M600 motor system, providing a whopping 1200 Watts Peak Power. This is EVELO's first Class 3 eBike release with the top speed set at 28mph right out of the box. As an added bonus, the Atlas is Throttle Ready, which means you can easily add and connect a handlebar mounted throttle if desired.
Seamless Gear Changes
The Atlas features an Enviolo CVT Hub with manual shifting. This means more mileage and less maintenance. The manual shifter gives you direct control and infinite gearing possibilities so you're always in the best gear possible. Turn the handlebar shifter just like a radio dial to tune into the perfect gear setting.
Primary Battery - up to 60 mile range
The primary battery is integrated into the downtube of the bicycle frame for a seamless look. This in frame battery design offers the best capacity-to-weight ratio possible, offering long range with the lowest weight possible. Because of it’s integrated design, It’s tough to tell that the Atlas is even an eBike. Combined with the black satin color, it’s a stealthy look.
You can charge the battery while it’s installed in the bike, or quickly remove the battery to charge it off of the bike if needed.
Boost your range up to 100-miles with the optional second battery upgrade.
Throttle Ready for Off-Road Use
The Atlas ships as a Class III eBike, but is throttle- ready for anyone looking for power- on- demand when in off-road mode.
Installing the throttle is a simple DIY procedure, which involves removing the grip, attaching the throttle, and connecting a single plug.
Please note that throttle use is intended for off-road riding only, and is not to be utilized on public roads. This part is an add-on to be installed by the rider after delivery.
Maintenance Free Gates Carbon Belt
The belt drive system weighs in at about half the weight of a traditional chain. With the Gates Carbon Drive™, you will enjoy a quiet and ultra-smooth riding experience everywhere you go.
Belt Drives are the perfect component to pair with Mid Drive motors and Internally Geared Hubs, such as the Enviolo CVT, since there are no external gears to deal with.
This all translates to the smoothest, cleanest, and longest lasting bicycle drivetrain possible.
Easy Assembly
It arrives almost fully assembled (95%), so you can be riding in no time.
Product Specifications
Sizing & Dimensions
| SIZING |
|
Recommended Rider Heights 5'6" - 6'3" Seat Height (Minimum / Maximum) 32.5" / 40.5" Seat to Pedal (Lowest / Highest) 25" / 35" Standover Height 28" Reach (Saddle to Handlebar) 26.5" Handlebar Height 42.5" Total Length (Tire to Tire) 75" Wheelbase (Center to Center) 46" |
Bike Specifications
|
Motor Transmission |
Bafang M600 120Nm Torque 600W, 1,200W Peak. Cadence & Torque Sensors Enviolo Trekking, twist shift (mechanical shifter) Gates CDX belt drive
|
|
Battery |
48V 15AH Samsung In Frame Battery - Optional 11.6AH Rear Rack Battery Add-On |
|
Charger |
48V 3A Charger |
|
Maximum Motor-Assisted Speed |
Up to 28 MPH |
|
Range |
Up to 60 Miles or 100 Miles with optional second battery |
|
Electric Assist |
5 levels of Pedal Assistance Standard / Optional Throttle |
|
Frame Fork |
Hydroformed Aluminum 6061 T6 Zoom 868 Boost Air suspension Fork |
|
Wheel |
27.5 DM40 double wall 40mm wide, tubeless compatible |
|
Tires |
Schwalbe Moto X 27.5 x 2.8" |
|
Brakes |
Zoom Hydraulic HB875E , 180mm front 160mm rear |
|
Seat |
Selle Royal Freccia with Royal Gel |
|
Stem Drivetrain |
Forged Alloy 4 bolt stem Gates CDX Drive with Enviolo Trekking CVT |
|
Shifters |
Enviolo Mechanical Twist Shifter |
|
Pedals |
Wellgo |
|
Lights |
Fully integrated UGOE Headlight (Alloy Casing,Cree LED, 400 Lumens, Side Cutouts), Integrated UGOE tail light |
|
Speedometer |
Bafang APT 860C full color IPS Display |
|
Fender |
Composite all weather front and rear fenders |
|
Rear Rack |
Optional, with second battery pack. Braze-ons for non-battery option |
|
Bicycle Weight (without battery) |
58 lbs |
|
Primary Battery Weight Secondary Battery Weight |
8.2 lbs 9.6 lbs w/ Rack |
|
Maximum Rider Weight |
Recommended for riders up to 350 lbs. Larger riders can be accommodated – contact us for details. |
Rider Position
Balanced Position
Leaning slightly forward, with your weight balanced between your hands and the saddle. It gives you a slightly sportier, more agile handling, with a comfortable ride and no strain on your lower back.
FAQs
Is the EVELO Atlas a good choice for me?
The Atlas has all of the features and components our customers have been requesting for years. The Enviolo CVT is argueably the best internally geared solution for Mid Drive eBikes on the market. The Gates CDX Belt Drive is the best of the best, and the Bafang M600 is one of the m
Does the Atlas have enough power for my terrain?
Yes. With 120 N.m of torque and 1200 peak watts, the Atlas has the power to tackle any terrain with any size rider. This is the most powerful fully street legal OEM production electric bicycle available.
Tell me more about the Dual Battery Option
The Atlas come standard with a large 15AH battery, which will provide up to 60 miles of range right out of the box. For those looking for a bit more adventure time, an additional rear rack mounted battery is available, which is plug and play with the ecxisting electrical system, making it easy to effectively double your available range to 120 miles per charge. This rack system can be added at the time of purchase, or at any time af
