EVELO eBike Motors

Easy to Use, Smooth Ride and Reliable

EVELO eBikes use top of the line motors in all of our products. These motors come from a few different manufacturers, all of which have a long track record of world class mechanical and electronic components.

Our Hub Drive bicycles use a 750W Bafang G060.750.DC rear hub motor.

This particular motor features an extra large core, and is designed for 750W continuous operation and peak power output of over 960 watts depending on the controller configuration. We’ve seen other companies use smaller motor cores and simply up the amperage of the controller to achieve 750W power consumption. These smaller motors will simply not last, as they are being overpowered - something to keep an eye out for. The technical specs for this particular motor are as follows;


Model: Bafang G060.750.DC
Position: Rear Hub Motor
Gear Reduction: One Stage Planetary
Rated Voltage: 36V / 43V / 48V
Compatible Wheel Diameters: 26in. / 27.5in. / 28
Max Operating RPM: 325
Rated Continuous Power: 750 Watts
Peak Power Output: 960 Watts
Maximum Torque Output: 80 N.m
Throttle: Yes
% Efficiency: +/- 80%
Weight: 10.14lb
Noise Rating: <55 dB
Operating Temperature: -4°F / 113°F
Ingress Protection: IP 65

Our Compass Tricycle and our Delta X models use a Bafang BBS02 motor system, which is massively popular in the DIY community, and has proven itself to be ultra reliable and easily serviced. The Compass is currently de-tuned to a 500 Watt configuration for safety, while our Delta X is tuned for a full 750 Watts, or 960 watts peak power output. This motor is phenomenally powerful with the highest torque rating available for street legal eBikes. The technical specs for this particular motor are as follows;

Model: Bafang BBS-02 G31-750W
Position: Mid Drive Motor
Gear Reduction: One Stage Spur Gear
Rated Voltage: 48V / 52V
Compatible Wheel Diameters: All Sizes
Max Operating RPM: 126
Rated Continuous Power: 750 Watts
Peak Power Output: 960 Watts
Maximum Torque Output: 120 N.m
Sensor Type: Speed / Cadence
Throttle: Yes
% Efficiency: +/- 80%
Weight: 9.47 lb
Noise Rating: <55 dB
Operating Temperature: -4°F / 113°F
Ingress Protection: IP 65

Some EVELO models use the latest DAPU motor system, which is manufactured exclusively for EVELO. This motor is compatible with the Gates Belt Drive, offers a seamless torque sensor for smooth engagement, a throttle, and plenty of torque for the majority of applications, and is our smoothest and most natural feeling Mid Drive eBike motor system to date. The technical specs for this particular motor are as follows;

Model: DAPU MM750
Position: Mid Drive Motor
Gear Reduction: One Stage Spur Gear
Rated Voltage: 36V / 48V
Compatible Wheel Diameters: All Sizes
Max Operating RPM: 106
Rated Continuous Power: 750 Watts
Peak Power Output: 960 Watts
Maximum Torque Output: 105 N.m
Sensor Type: Torque & Cadence
Throttle: Yes
% Efficiency: > 80%
Weight: 9.48 lb
Noise Rating: <52 dB
Operating Temperature: -2°F / 110°F
Ingress Protection: IP 65
